ACS310-03E-03A6-4 AC drives

Get a Price/Quote

ACS310-03E-03A6-4 AC drives Specification

Efficiency
Up to 98%

Shape
Rectangular

Humidity %
595% RH, non-condensing

IP Rating
IP20

Connector Type
Screw Type Terminals

Insulation Material
High Grade Insulating Plastic

Surface Finish
Powder Coated

Overheating Protection
Temperature Controlled Fan, Over Temperature Alarm & Trip

Feature
PID Control, Built-in Macros, Pump and Fan Control, Flying Start, Built-in Potentiometer

Mounting Type
Wall/Panel Mount

Operating Temperature
-10C to +50C

Power Factor
0.98 (typical)

Product Type
AC Drive (VFD)

Application
Pumps, Fans, General Purpose Motor Control

Protection Level
Overload, Overvoltage, Overcurrent, Short-Circuit

Frequency (MHz)
47-63 Hz

Rated Voltage
380-480 V AC

Energy Consumption
Optimized for energy savings with built-in energy optimizer

Output Type
Three Phase AC Motor Output

Color
Grey

Dimension (L*W*H)
70 x 203 x 239 mm

Weight
1.7 kg

Phase
Three Phase

Input Voltage
380-480 V AC

Size
Frame size R0

No Of Poles
3

Connection Type
Screw Terminal

Material
Metal & Engineering Plastic

About ACS310-03E-03A6-4 AC drives

ABB ACS310 drive dedicated to optimize your variable torque applications, such as booster pumps and centrifugal fans. Designed with a powerful set of features that vary the driveAAAs performance in response to changes in pressure, flow or other external data. Helping you to save on operating costs, increase energy efficiency and reduce CO2 emissions. ABB general purpose drive, ACS310 is easy to select and easy to use. It is enough for most basic applications with no high overload demands. ACS310 is suitable for wide range of variable torque applications and simple machines.

The compact design and uniform dimensions make cabinet mounting of the drive straightforward, thereby providing a fast and space saving installation. The ACS310 drives have an embedded Modbus interface for system monitoring that saves the cost of external fieldbus devices and enables to integrate the drives easily with PLC. When combined with preprogrammed application macros, an intuitive user interface and several assistant screens, installation time is further reduced while speeding up parameter setting and drive commissioning.

The ACS310 drives meet the needs of OEMs, logistical and technical distributors as well as the requirements of end users with pumping and ventilation applications.

Comprehensive Control for Industrial Applications

The ACS310-03E-03A6-4 AC drive is built to excel in controlling pumps, fans, and numerous general-purpose motors in industrial environments. This model delivers impressive reliability, managing loads with features like built-in macros, PID control, and an integrated energy optimizer for substantial energy savings. Its compact, panel-mountable design with IP20 rating and powder-coated finish ensures durability and facilitates easy installation, even in tight spaces.

Advanced Protection and Diagnostic Features

This AC drive incorporates comprehensive protection mechanisms, including overload, overvoltage, overcurrent, and short-circuit safeguards. The temperature-controlled fan and over-temperature alarm minimize risks associated with overheating, extending lifespan and ensuring safe operation. The drive's status is easily monitored via clear LED indicators and optional keypad access, making diagnostics and maintenance straightforward.

FAQ's of ACS310-03E-03A6-4 AC drives:

Q: How do I program the ACS310-03E-03A6-4 AC drive?

A: The ACS310-03E-03A6-4 can be programmed using either the front panel controls or a computer via USB/RS485 connection (optional). The interface supports parameter adjustments directly or through PC software for detailed configuration.

Q: What are the typical applications for this AC drive?

A: This drive is optimized for pumps, fans, and general-purpose industrial motor control tasks. Its built-in macros, PID features, and energy optimizer ensure tailored performance across a range of equipment types.

Q: When should I use the built-in braking unit?

A: The built-in braking unit is beneficial during rapid deceleration or stopping of connected motors, particularly in situations where sudden changes occur or for processes with high inertia loads that require quick stops.

Q: Where can I monitor the drive's operational status?

A: Operational status is displayed via LED status indicators on the drive itself. For enhanced monitoring and control, an optional keypad or external communication module can be used to access detailed parameters.

Q: What is the benefit of the integrated C2 EMC filter?

A: The integrated C2 category EMC filter reduces electromagnetic interference, ensuring compliance with IEC and other relevant standards, which is essential for installations where low electrical noise is required.

Q: How does the ACS310 drive contribute to energy efficiency?

A: Equipped with a built-in energy optimizer and high-efficiency operation (up to 98%), the drive reduces energy consumption, particularly when used with variable torque loads like pumps and fans.
