Altivar Atv630d37n4

Price 1 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Altivar Atv630d37n4 Specification

Drive Type
Variable Frequency Drive

Sensor Type
Temperature sensor compatible

Load Capacity
Suitable for 37 kW Motor

Features
Integrated EMC Filter, Graphic Display, Inbuilt PLC

Frequency
50/60 Hz

Cable Length
User Defined

Automation Grade
Automatic

Mounting Type
Wall Mounted

Connectivity Type
Ethernet, Modbus, CANopen

Application
Industrial Motor Control

Control Type
V/F, Sensorless Vector Control

Screen Size
2.4 inch display

Processor Type
Microprocessor based

Remote Control
Yes

Weight
38.5 kg

Speed Range
1 - 100 Hz

IP Rating
IP21

Phase
Three Phase

Material
Plastic and Metal

Power
37 kW

Temperature
-15C to +60C

Voltage
380-480 Volt (v)

Product Type
Variable Frequency Drives

Warranty
1 Year

Relay Output
2

Digital Input
6

Overload Capacity
120% for 60 s

Analog Output
2

Model Number
ATV630D37N4

Analog Input
3

Short Circuit Protection
Integrated

Enclosure
Enclosed - IP21

Digital Output
3

Cooling
Fan forced air cooling

Altitude
Up to 1000 m without derating

Motor Control
Asynchronous and Synchronous motors

Product Series
Altivar Process ATV630

Display Type
Graphical LCD

Braking Unit
Integrated

Conformal Coating
On PCBs for harsh environments

Standards
IEC 61800-5-1, IEC 61800-3

Humidity
5% to 95% non-condensing

Altivar Atv630d37n4 Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Telegraphic Transfer (T/T)

Delivery Time
3-4 Days

Main Export Market(s)
Asia

Main Domestic Market
Gujarat

About Altivar Atv630d37n4

Altivar Atv630d37n4

Alfa-numeric and graphical display to monitor trends and values
Inbuilt features dedicated for Pump eg. Pump Curves, Pipe fill, Anti Jam, Pipe cleaning etc
Calculative power consumption with respect to flow (kwh/m^3)
VFD designed for 50 deg C without derating.
In Built choke & EMC Filter
Integrated Modbus & Modbus TCP/IP (Ethernet)
Web server inbuilt
Ethernet & Modbus in Built
QR code feature in built to get documents acess on line and register service request directly from QR code.
